PRODUCTION PROCESS

GOOD HOUSEWARE

Technical Questions →

Idea

Brand customers tell us their idea or show us any photos of what they want to make

2D Drawing

Then, we will start 2D drawing to confirm the design and size according to the customer’s request.

We will make 3D drawing with details.

We will make a 3D drawing with the details.

Mass production

Customer confirms the structure and function, then we will arrange bulk production.

Trial production

We will send a test sample to the brand customer.

Mould

Open mould as customer’s request

Outer Shell Processing

Raw Material (Roller Of Plate) To Tube → Cut Tube → Hydroforming → Segment (1 Into 2) → Expansion Shaped → Roll Middle Angle → Shrink Bottom End → Cut The Extended Bottom End → Beat Out The Reinforced → Polishing The Welding Seam → Adding 3rings → Stamping Embossed Logo On One Side (If There Is) → Flat Top End → Beat Out The Bottom End → Flat The Bottom End → Cleaning Drying → Test Knock Pit → Qualified Shell

Inner Shell Processing

Assembly Process To Connect The Outer Shell With The Inner Shell

Insert Inner To The Outer Shell, Form Cup Mouth → Welding Cup Mouth → Cover The 2nd Bottom Cover → Welding This Bottom Pad → Checking Welding Quality → Add Inhale Agent On The Bottom Cover By Spot Welding → Vacuum → 1st Heat Retention Checking → Electrolytic → Polishing → 2nd Heat Retention Checking → Check To Polish → Adding The 3rd Bottom Cover → Spray Painting / Powder Coating (If There Is) → Random Temperature Testing → Qualified Cup Body → Graphic Decorating (Add By Embossing / Silkscreen Printing / Laser Engraving / Air Gas Printing / Uv Printing) →

Screw The Lid Onto The Steel Cup Body

Injection Of All Lid Parts → Assemble Lid → Add The Water Leakage Seal → Screw Lid Onto Steel Cup Body → Random Water Leakage Testing → Packaging → Finished Storage →
